Description
SHO-DDX05 is a high-performance digital radiography system designed for demanding clinical environments. Featuring sophisticated technology, it supports high-speed operation, excellent heat dissipation, and extended lifespan, making it ideal for continuous clinical use.
Key Features:
-
High-Frequency X-ray Generator: Offers high inverse frequency, large power output, and superior X-ray quality.
-
Intelligent High Voltage Control: Equipped with multiple APR settings for optimized imaging.
-
Advanced a-Si CsI Flat Panel Detector: Delivers high conversion efficiency and low-dose digital image acquisition.
-
Precision Digital Image Processing System: Provides advanced post-processing capabilities to meet diverse clinical diagnostic needs.
-
Manual Collimator with Auto Lamp Timer: Ensures precise targeting with automatic 30-second LED illumination.
Technical Specifications:
-
Maximum Image Window: 440mm x 440mm (SID = 100cm)
-
Anode Type: Rotating anode
-
Focal Spot Size: 0.6 mm / 1.2 mm
-
Maximum Voltage: 150kV
-
Anode Speed: 2800 rpm
-
Inherent Filtration: 1.0 mm Al
-
Anode Heat Capacity: 300 KHU
-
Cooling Rate: 870W
-
Housing Heat Capacity: 900 kJ
-
Lamp: AC/DC 24V, 5W
-
Illumination Timer: 30 seconds (automatic)
-
Illuminant Type: LED
